FORCE MEASUREMENT EQUIPMENT


            AP Crane Scale Hardware Kits




                                                           The AP Dynamometer is designed to work with oversized shackles and various
                                                           hooks to provide complete flexibility to support your required application.

                                                           Feature for feature — Dillon Dynamometer sets the standard.
                                                           •  Available in Low, Intermediate and High Range Models: Capacities from 1000
                                                              to 20,000 pounds. Capacities from 500 to 10,000 kg.
                                                           •  Anti-parallax Dial and Pointer: Easy to read even at an angle.   Dynamometers/Crane Scales
                                                           •  Tare Capability: Tare loads up to 20% of capacity can be zeroed out by means of
                                                              zero control.
                                                           •  Dust Protection: Pinion gear, sector gear and shafts are mounted in precision
                                                              aircraft bearings, permanently sealed against dust and dirt. Oiling is never
                                                              required.
                                                           •  Tough Construction:– Mechanism case is a heavy aluminum alloy casting,
                                                              tough enough to resist even heavy blows.
                                                           •  Ingenious Design: Utilizes a specially designed alloy steel beam that translates
                                                              force to pounds. Full scale reading results from beam deflection of only 0.026”.
                                                              Applied loads are indicated instantly.
                                                           •  Reduced Wear: Pinion and sector gears are cut from stainless steel and
                                                              hardened aluminum. Use of these dissimilar materials greatly reduces friction
                                                              and wear.
                                                           •  Protective Finish: Scale cases are coated with a baked-on powder paint process
                                                              making them resistant to chips, scratches, rust and corrosion.
                                                           •  Maximum indicator: Remains in position to indicate peak load point after load
                                                              is removed from scale.
                                                           •  Hardware Kits: Now offered as an add on feature for the AP Dynamometer.


            Capacity and Resolution
                                              Net    Gross   Hook Kit   Hook Kit
                      Capacities & Dial   Length  Weight   Weight   Net Weight   Ship Weight
             Capacity  Divisions (lb)  in (mm)   lb (kg)  lb (kg)  lb (kg)  lb (kg)
             Low      1,000 x 5     25.5 (647)  28 (12)  62 (28)  13 (5)  44 (19)
             Low      2,000 x 10    25.5 (647)  28 (12)  62 (28)  13 (5)  44 (19)
             Low      5,000 x 20    25.5 (647)  28 (12)  62 (28)  13 (5)  66 (29)
             Low      10,000 X 50   25.5 (647)  28 (12)  62 (28)  20 (9)  66 (29)
             Med      *20,000 x 100  29.75 (755)  48 (21)  83 (37)  42 (19)  77 (34)

                                             Net    Gross   Hook Kit   Hook Kit
                      Capacities & Dial  Length  Weight   Weight   Net Weight   Ship Weight
             Capacity  Divisions (kg)  in (mm)   lb (kg)  lb (kg)  lb (kg)  lb (kg)
             Low      1000 x 5     25.5 (647)  28 (12)  62 (28)  13 (5)  44 (19)
             Low      2000 x 10    25.5 (647)  28 (12)  62 (28)  13 (5)  44 (19)
             Low      5000 x 20    25.5 (647)  28 (12)  62 (28)  20 (9)  66 (29)
             Med      *10,000 x 50  29.75 (755)  48 (21)  83 (37)  42 (19)  77 (34)           Heavy-duty reinforced plywood crate



            Crane Specifications

            Accuracy: To ±0.5% of full scale
            Tare adjustment: Up to 20% of full scale range
            Ultimate safety factor: 5:1(*4:1 for 20,000 lb and 10000 kg)
            Dial diameter: 10”
            Scale length: (from inside of eye to inside of hook)
               Low Range: 25½”
               Medium Range: 29¾”
            All kits are shipped complete to allow direct interface to the AP Dynamometer (not included).
               Hardware kits are shipped in separate packaging.
               Standard AP Crane Scale Hardware Kit includes: swivel hook, oversized shackle assembly and
               wooden shipping/storage crate.
